9-EN
01GB05CDA9886.fm
ALPINE CDA-9886M 68-12118Z86-A (EN)
Presetting Stations Manually
1
Select the radio band and tune in a desired radio
station you wish to store in the preset memory.
2
Press and hold, for at least 2 seconds, any one of the
preset buttons (1 through 6) into which you wish
to store the station.
The selected station is stored.
The display shows the band, preset number and station
frequency memorized.
• A total of 18 stations can be stored in the preset memory (6 stations
for each band; FM1, FM2 and AM).
• If you store a station in a preset memory which already has a station,
the current station will be cleared and replaced with the new station.
Presetting Stations Automatically
1
Press BAND repeatedly until the desired radio band
is displayed.
2
Press and hold TUNE/A.ME for at least 2 seconds.
The tuner will automatically seek and store 6 strong stations
in the selected band. They will be stored into preset buttons
1 to 6 in order of signal strength.
When the automatic memory has been completed, the tuner
goes to the station stored in preset location No.1.
• If no stations are stored, the tuner will return to the original station
you were listening to before the auto memory procedure began.
Tuning to Preset Stations
1
Press BAND repeatedly until the desired band is
displayed.
2
Press any one of the station preset buttons
(1 through 6) that has your desired radio station in
memory.
The display shows the band, preset number and frequency
of the station selected.
Frequency Search Function
You can search for a radio station by its frequency.
1
Press and hold /ENT for at least 2 seconds in
Radio mode to activate Frequency search mode.
2
Turn the Rotary encoder to select the desired
frequency.
3
*
Press /ENT to receive the selected frequency.
* Operation is not required during HD Radio reception.
• Press and hold /ESC for at least 2 seconds in the search mode to
cancel. Or, the search mode will be canceled if no operation is
performed for 10 seconds.
Receiving a Multicast Station
(HD Radio mode only)
Multicasting is the Ability to broadcast multiple program streams over a
single FM frequency. This increases the amount and diversity of content
choices. A maximum of eight multicast station channels can be selected
on this unit.
When multicast station is received, the program number
and the SPS indicator lights up. Press or to select
the desired program service.
Receiving the Multicast Station Program Service.
Program Service example:
Multicast Radio Station Program No. Program Service
87.7 MHz No.1
MPS
: Main Program Service
87.7 MHz No.2 SPS: Sub-program Service
87.7 MHz No.3 SPS: Sub-program Service
|
|
|
|
87.7 MHz No.8 SPS: Sub-program Service
Program No.
SPS Indicator
01GB00CDA9886M.book Page 9 Monday, March 17, 2008 4:05 PM
