Acknowledgements
Our thanks are due to APS Motorcycles of Wells (formerly
Fran
Ridewood
& Co), Paul Branson Motorcycles of Yeovil, and
CSM of Taunton, who supplied the machines featured in this
manual.
We would also like to thank the Avon Rubber Company, who
kindly supplied information and technical assistance on tyre
fitting; NGK Spark Plugs (UK) Ltd for information on spark plug
maintenance and electrode conditions and Renold Limited for
advice on chain care and renewal.
About this manual
The author of this manual has the conviction that the only
way in which a meaningful and easy to follow text can be
written is first to do the work himself, under conditions similar
to those found in the average household. As a result, the hands
seen in the photographs are those of the author. Even the
machines are not new: examples that have covered a consider-
able mileage were selected so that the conditions encountered
would be typical of those found by the average owner.
Unless specially mentioned, and therefore considered
essential, Honda service tools have not been used. There is
invariably some alternative means of slackening or removing
some vital component when service tools are not available and
risk of damage has to be avoided at all costs.
Each of the six Chapters is divided into numbered Sections.
Within the Sections are numbered paragraphs. In consequence,
cross reference throughout this manual is both straightforward
and logical. When a reference is made 'See Section 5.12' it
means Section 5, paragraph
12
in the same Chapter. If another
Chapter were meant, the text would read 'See Chapter 2,
Section 5.12'. All photographs are captioned with a
Section/paragraph number to which they refer and are always
relevant to the Chapter text adjacent.
Figure numbers (usually line illustrations) appear in
numerical order, within a given Chapter. Fig.
1.1
therefore refers
to the first figure in Chapter
1.
Left-hand and right-hand
descriptions of the machines and their component parts refer to
the right and left of a given machine when the rider is seated
normally.
Motorcycle manufacturers continually make changes to
specifications and recommendations, and these, when notified,
are incorporated into our manuals at the earliest opportunity.
We take great pride in the accuracy of information given in
this manual, but motorcycle manufacturers make alterations and
design changes during the production run of a particular
motorcycle of which they do not inform us. No liability can be
accepted by the authors or publishers for loss, damage or injury
caused by any errors in, or omissions from, the information given.
