About the Control Panel
21
4 Collated (Sort)
copying
Indicates whether or not collated (Sort) copying is
selected. For details on selecting collated (Sort)
copying, refer to “Setting Collated (Sort) Copying” on
page 167.
5 2in1/4in1 copy-
ing
Indicates whether or not 2in1/4in1 copying is
selected. For details on selecting 2in1/4in1 copying,
refer to “Setting 2in1/4in1 Copying” on page 160.
6 Double-sided/
single-sided
copying
Indicates whether double-sided copying or sin-
gle-sided copying is selected. For details on select-
ing double-sided/single-sided copying, refer to
“Setting Duplex (Double-Sided) Copying” on page
165.
7 Copy function Indicates the copy function that is set. For details on
setting a copy function, refer to “Setting a Copy
Function” on page 161.
8
UTILITY
Select this menu item to change the various
machine settings. For details, refer to “UTILITY
Menu” on page 33.
9
REPORT/STA-
TUS
Select this menu item to view the total number of
pages printed by this machine and the results of fax
transmissions/receptions as well as to print the
reports. For details, refer to “REPORT/STATUS
Menu” on page 29.
10
PS/PCL
PRINT
Select this menu item to print or delete jobs stored
on the machine's hard disk (optional) and to change
the settings related to PS/PCL printing. For details,
refer to “PS/PCL PRINT Menu” on page 71.
11
MEMORY
PRINT
Select this menu item to perform memory direct
printing operations and to specify settings for these
operations. For details, refer to “MEMORY PRINT
Menu” on page 103.
" This menu item appears only if an optional
hard disk kit or a CompactFlash card is
installed.
No. Indication Description
