2-4
2.3.2 CONNECTING THE SC-215 TO A WINDOWS
WORKSTATION TO WORK AS A SCANNER
Figure 2-3 SC-215 Cable Connection
Power
Cable
USB Cable
To Power
Outlet
To PC USB Port
