2.3 CONNECTING THE CABLE

2.3.1 CONNECTING THE SC-215 TO A PRINTER TO

WORK AS A COPIER

Connect the power cable and signal cable as

shown below.

Figure 2-2 Connecting the SC-215 to a printer

To Printer

To Power Outlet

Power Cable

Printer Cable
