MEASUREMENT FOUNDATION

GroundDrill - 12

6

4. Specications

Engine type 4 stroke, air-cooled

Air-fuel mixture unleaded gasoline with a minimum of 92 octane

Displacement 159 cc

Ignition TCI

5. Preparation before operation

Set handles on the frame of the auger: handle with throttle lever arm should be at the left of the fuel tank. Screw bolts into the holes

of the handles and frame and tighten. Tighten with the help of the instrument that comes with the equipment.

CHOKER CABLE CONNECTION

Connect cable of the choker to the control lever.

WIRING LEADS

Connect leads (x2) between engine and button of turning off the ignition. Make sure colors match and connections are securely tight.

CONNECTION OF THE AUGER TO THE REDUCTION GEAR

Match power shaft of the reduction gear and drill shank. Place power shaft into the shank. Fix the connection with the bolt.
