Philips 271S4LPYEB [25/46] Technical specifications
![Philips 271S4LPYEB [25/46] Technical specifications](/views2/1128793/page25/bg19.png)
23
5. Technical `Specications
• Since some dark colored clothing tends to
absorb infrared signals even when the user
is within 100 cm or 40 inches of the display,
step up signal strength when wearing black
or other dark clothes.
Hot key Sensor distance
Landscape/Portrait mode
Above illustrations are for reference purpose only
How to adjust settings
If PowerSensor is not operating correctly
inside or outside the default range, here’s how
to fine-tune detection:
• Press the PowerSensor hot key
• You will find the adjustment bar.
• Adjust the PowerSensor detection
adjustment to Setting 4 and press OK.
• Test the new setup to see if PowerSensor
properly detects you in your current
position.
• PowerSensor function is designed to work
in Landscape mode (horizontal position)
only. After PowerSensor turn on it, it will
automatically turn Off if the monitor
is used in Portrait mode (90 degree/
vertical position); it will automatically turn
ON if monitor is returned to its default
Landscape position.
Note
A manually selected PowerSensor mode
will remain operational unless and until it is
readjusted or the default mode is recalled. If
you nd that the PowerSensor is excessively
sensitive to nearby motion for some reason,
please adjust to a lower signal strength.
5. Technical Specifications
Picture/Display
Monitor Panel Type TFT-LCD
Backlight LED
Panel Size 27" W (68.6cm)
Aspect Ratio 16:9
Pixel Pitch 0.31 x 0.31 mm
Brightness 300 cd/m²
SmartContrast 20,000,000:1
Contrast Ratio (typ.) 1000:1
Response Time (typ.) 5ms
Optimum Resolution 1920 x 1080 @ 60Hz
Viewing Angle 170° (H) / 160° (V) @ C/R > 10
Display Colors 16.7M
Vertical Refresh Rate 56 Hz - 76 Hz
Horizontal Frequency 30 kHz - 83 kHz
sRGB YES
Connectivity
Signal Input DisplayPort, DVI(Digital), VGA( Analog)
Input Signal Separate Sync, Sync on Green
Convenience
User Convenience
OSD Languages
English, French, German, Spanish, Italian, Russian,
Simplified Chinese, Portuguese, Turkish, Dutch, Swedish, Finnish,
Polish, Czech, Korean, Japanese, Hungarian, Ukraine, Brazil
Portuguese, Greek, Traditional Chinese
Other Convenience Kensington Lock
Plug & Play Compatibility DDC/CI, sRGB, Windows 7/Vista/XP, Mac OSX, Linux
Stand
Tilt -5 / +20
Power
On Mode 29.3W (typ.)
On Mode (ECO Mode) 14W (typ.)
Energy Consumption
(EnergyStar 5.0 test method)
AC Input Voltage at
100VAC +/-5VAC,
50Hz +/-3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/-3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/-3Hz
Normal Operation (typ.) 21.3W 21.3W 21.3W
Sleep (Standby) 0.3W (typ.) 0.3W (typ.) 0.3W (typ.)
Off 0.1W (typ.) 0.1W (typ.) 0.1W (typ.)
Heat Dissipation*
AC Input Voltage at
100VAC +/-5VAC,
50Hz +/-3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/-3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/-3Hz
