6
RESET
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
AIR CONDITIONER
REMOTE CONTROL
Press the remote control’s button
1
TO TURN ON OR OFF THE UNIT
• PleasebeawareoftheOFFindicationontheremote
control display to prevent the unit from starting/stopping
improperly.
2
TO SET TEMPERATURE
• Selectionrange:16˚C~30˚C.
• Operatingtheunitwithintherecommendedtemperature
could induce energy saving.
COOLmode:26˚C~28˚C.
HEATmode:20˚C~24˚C.
DRYmode:1˚C~2˚Clowerthanroomtemperature.
3
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unitselectstheoperationmodeaccordingtotheroom
temperature.
• Onceautomodeisselected,theunitwilloperateatthe
standard setting temperature.
•Tochangethestandardsettingtemperature,press
for “ ” or for “ ”.
Room
temperature
Operation
mode
Standard setting
temperature
(+2°C)
(–2°C)
23°C & above Cool 25°C 27°C 23°C
Below 23°C Dry 22°C 24°C 20°C
Below 20°C Heat 21°C 23°C 19°C
HEAT mode - To enjoy warm air
• Inheatmode,itmaytakeawhilefortheunittowarmup.
ThePOWERindicatorblinksduringpreheating.
COOL mode - To enjoy cool air
• Usecurtainstoscreenoffsunlightandoutdoorheatto
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unitoperatesatlowfanspeedtogiveagentlecooling
operation.
Remote Control display
4
TO SELECT FAN SPEED (3 OPTIONS)
FAN SPEED
• ForAUTO,theindoorfanspeedisautomaticallyadjusted
according to the operation mode.
5
TO ADJUST VERTICAL AIRFLOW DIRECTION
(5 OPTIONS)
AIR SWING
• Keepstheroomventilated.
• InCOOL/DRYmode,ifAUTOisset,thelouverswingup/
down automatically.
• InHEATmode,ifAUTOisset,thelouverxat
predetermined position.
6
PRESS TO RESTORE THE REMOTE CONTROL’S
DEFAULT SETTING
Maximumdistances:8m
INDICATOR
(Green)
(Orange)
RESET
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
AIR CONDITIONER
1
4
5
6
3
2
F567652_EN.indd 6 2010-12-20 11:27:42
