Overall

─ 18 ─

Exploded View and Parts List

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Upright ASSY 1 21 Domed Aluminium Cap 10

2 Right Bottom Frame ASSY 1 22 Socket Head Cap Screw M12*135 8

3 Left Bottom Frame ASSY 1 23 Socket Head Cap Screw M12*35 4

4 Front Cross Frame ASSY 1 24 Flat Head Cap Screw M12*30 8

5 Rear Cross Frame ASSY 1 25 Socket Head Cap Screw M20*35 4

6 Right Arm Frame ASSY 1 26 Button Head Cap Screw M10*75 2

7 Left Arm Frame ASSY 1 27 Socket Head Cap Screw M12*145 2

8 Right Power Frame ASSY 1 28 Socket Head Cap Screw M10*145 1

9 Left Power Frame ASSY 1 29 Socket Head Cap Screw M12*85 8

10 Connecting Rod Frame ASSY 2 30 Flat Head Cap Screw M10*25 2

11 Seat Frame ASSY 1 31 Button Head Cap Screw M10*30 2

12 Idier Wheel ASSY 2 32 Nylon Lock Nut M12 14

13 Aluminium Shield 4 33 Nylon Lock Nut M10 1

14 Foam Tube Φ25*2.5*546 1 34 Flat Washer Φ13*Φ24*1.5 32

15 Foam Pad 2 35 Flat Washer Φ11*Φ20*2 6

16 Back Pad 1 36 Hex Key S=10 1

17 Seat Pad 1 37 Hex Key S=8 1

18 Pivot Shaft Φ30 4 38 Hex Key S=6 1

19 Pull Spring 1 39 Hex Key S=3 1

20 Supporting Sleeve 1 40 Hex Key S=17 1
