Exploded View and Parts List

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Left Upright Frame ASSY 1 19 Aluminium Ring Φ90 4

2 Right Upright Frame ASSY 1 20 Small Domed Cap 4

Front seat Pad Frame WeLding ASSY

1 21 Domed Aluminium Cap 2

4 Moving seat Pad Frame ASSY 1 22 Extension Spring 1

5 Rear Link Frame ASSY 1 23 Button Head Cap Screw M10*20 4

6 Left Leg Frame ASSY 1 24 Button Head Cap Screw M10*30 7

7 Right Leg Frame ASSY 1 25 Button Head Cap Screw M10*75 2

8 Left Handle ASSY 1 26 Flat Head Cap Screw M10*25 2

9 Right Handle ASSY 1 27 Socket Head Cap Screw M10*25 2

10 Guide Rod ASSY 2 28 Socket Head Cap Screw M12*30 4

11 Left Inside Bearing Fixed Plate ASSY 1 29 Socket Head Cap Screw M12*130 4

Right Inside Bearing Fixed Plate ASSY

1 30 Socket Head Cap Screw M12*135 4

Left Outside Bearing Fixed Plate ASSY

1 31 Socket Head Cap Screw M12*155 6

Right Outside Bearing Fixed Plate ASSY

1 32 Nylon lock Nut M12 14

15 Front Seat Pad 1 33 Flat Washer Φ11*Φ20*2 9

16 Rear Seat Pad 1 34 Flat Washer Φ11*Φ38*2 2

17 Back Pad 1 35 Flat Washer Φ13*Φ24*1.5 32

18 FOAM 2
