![Loewe Individual 32 Selection HD+ [25/60] Favourites list right column must be selected if not change the list with](/img/pdf.png)
Loewe Individual 32 Selection HD+ [25/60] Favourites list right column must be selected if not change the list with
![Loewe Individual 32 Selection HD+ [25/60] Favourites list right column must be selected if not change the list with](/views2/1013759/page25/bg19.png)
25 -
Managing stations
Add station to favourites list
Go to the left column (all stations).
P+/P– Scroll in the pages of the station list if necessary.
Mark station or select station with the numeric
buttons (
for alphabetical station sorting enter the
initial letter
) which is to be transferred as a
favourite to the favourites list.
OK transfers the station to the favourites list.
The new station is inserted at the end of the
favourites list.
Proceed in the same manner with additional stations.
Delete station from favourites list
Favourites list (right column) must be selected.
If not, change the list with .
mark station to be deleted.
OK removes the marked station from the favourites list.
or:
Red button: Activates Clear favourite list.
OK confirms clear list.
Move / change order of stations in the favourites list
Favourites list (right column) must be selected.
If not, change the list with .
mark station to be moved.
Yellow button: Activates Move station.
Select insertion position at which the marked
station is to be inserted.
The insertion position can also be selected with
the numeric buttons.
OK to execute the move.
END
INFO
OK
OK
P+
P–
09
-
All stations
Select/change favourites
(LQV3OXV ۽
=')LQIRNDQDO ۽
=')GRNXNDQDO ۽
=')WKHDWHUNDQ ۽
0'5)(516(+ ۽
UEE%HUOLQ۽
UEE%UDQGHQEXUJ۽
DUWH ۽
.L.D ۽
1'5)6++ ۽
1'5)609 ۽
1'5)61'6 ۽
Stations of Favourites 1
%5DOSKD ۽
VDW ۽
(LQV([WUD ۽
(LQV)HVWLYDO ۽
6$7۽
57/ ۽
DUWH ۽
Adopt to favourite list
Select station Next favourite list
Clear favourite lsit Change sorting
3DJHחי
END
INFO
OK
OK
P+
P–
All stations
Select/change favourites
(LQV3OXV ۽
=')LQIRNDQDO ۽
=')GRNXNDQDO ۽
=')WKHDWHUNDQ ۽
0'5)(516(+ ۽
UEE%HUOLQ۽
UEE%UDQGHQEXUJ۽
DUWH ۽
.L.D ۽
1'5)6++ ۽
1'5)609 ۽
1'5)61'6 ۽
Stations of Favourites 1
'DV(UVWH ۽
=') ۽
:'5.¸OQ۽
%D\ULVFKHV)6 ۽
DUWH ۽
3KRHQL[۽
%5DOSKD ۽
VDW ۽
(LQV([WUD ۽
(LQV)HVWLYDO ۽
6$7۽
57/ ۽
Select insert position Select station
Execute move Cancel move
3DJHחי
09
-
