Loewe Individual 32 Selection HD+ [27/60] Picture in picture
![Loewe Individual 32 Selection HD+ [27/60] Picture in picture](/views2/1013759/page27/bg1b.png)
27 -
Change position of the PIP
Other than the status line, which may possibly be
displayed, no other display is shown on the screen:
Move the PIP into a corner of the screen.
Moving the small picture is possible if there is a green,
white and blue frame.
The position of the small picture can also be selected
under Position in the PIP menu.
Switch to Split Screen
PIP menu open.
Select Type,
go to the menu line below.
Select Split Screen.
Configure Picture in Picture (PIP) mode
In the PIP menu, you can set the PIP type (split screen or small PIP) and
the position of the small picture.
Start PIP menu
PIP mode started,
if not, press PIP button.
The frame is green,
if not, press the green button.
Call the PIP menu.
Switch over to small picture
PIP menu open.
Select Type,
go to the menu line below.
Select Small PIP.
Picture in Picture
ENDINFO
Split screen
Type
TV menu
Settings
PIP
Small PIP
END
INFO
Split screen
Type
TV menu
Settings
PIP
mall PIP
Sm
ENDINFO
Split screen
Type
TV menu
Settings
PIP
m
all PIP
S
m
