Preparations

When installing the camera on a wall or a ceiling, there are four methods as specified below.

(☞ Pages 20 and 21).

 • Usingthetwo-gangjunctionbox

 • Installingthecameradirectlyontheceilingorwall

 • UsingtheoptionalceilingmountbracketWV-Q168(forembeddedinstallationonaceiling)

 • UsingtheoptionalceilingmountbracketWV-Q105*

(for direct mounting on a ceiling)

Important:

 • Procure4screws(M4)tosecurethecameratoawalloraceilingaccordingtothematerialof

the installation area. In this case, wood screws and nails should not be used. For mounting a

camera on a concrete wall, use an anchor bolt (for M4) or an AY plug bolt (M4) for securing.

(Recommended tightening torque: 1.6 N·m {1.18 lbf·ft})

 • Requiredpull-outcapacityofasinglescrew/boltis196N{44lbf}ormore.

 • Ifaceilingboardsuchasplasterboardistooweaktosupportthetotalweight,theareashall

be sufficiently reinforced or the optional ceiling mount bracket for the camera, WV-Q105, must

be used.

The mounting conditions of the camera are described as follows:

Installation

place

Applicable mount

bracket

Recommended

screw

Number of

screw

Minimum pull-out

strength (per 1 pc.)

Ceiling/wall Two-gang junction

box

M4 4 pcs. 196 N {44 lbf}

Ceiling/wall (Direct mounting) M4 4 pcs. 196 N {44 lbf}

Ceiling WV-Q168 (approx.

280 g {0.8 lbs})

– – *

Ceiling WV-Q105*

(approx.

150 g {0.8 lbs})

– – *

*1 PAL models only

*2 Make sure that the installed mount bracket can support more than 5 times of the weight of the

camera.
