BBE 382i Sonic Maximizer [6/12] Specifications
![BBE 382i Sonic Maximizer [6/12] Specifications](/views2/1000139/page6/bg6.png)
6
SPECIFICATIONS
Frequency
Response
process mode Program controlled
bypass mode 5Hz to 30kHz +/-0.5dBu, -10dBu input
THD in process mode less than 0.1% at -10dBu input, 20-20kHz
Maximum Output
+20dBu
(may vary due to control settings)
Input Impedance 47k Ohms, unbalanced 1/4” phone jack or RCA jack
Output Impedance 1k Ohms, unbalanced 1/4” phone jack or RCA jack
Sensitivity -45dBu for maximum process
Maximum Process +12dBu boost at 5kHz
Lo Contour +12dBu boost at 50Hz
Power Requirements
U.S., Canada & Japan models: 120VAC, 50/60Hz, 8 WATTS
Standard model: 220VAC, 50/60Hz, 8 WATTS
Fuse Replace with 250VAC, 200mA fastblow type fuse
Dimensions 19”(W) x 5.5”(D) x 1.7”(H)
Shipping Weight 6.5 lbs.
* 0dBu = 0.775mVrms
Note: Due to continuing product improvement, specications and design are subject to change without notice.
The BBE Sonic Maximizer is a line level signal processor and
is to be connected prior to the power amp in any audio sys-
tem. Signicant damage may be inicted to the bbe sonic
maximizer or any subsequent component in the system in
the event the output of a power amp is connected directly to
the input of the BBE Sonic Maximizer.
