LG V-C4243 HTU [4/8] Connecting the flexible hose

– 4 –

Please read all the following information,

which contains important instructions for

the safety, the use and the maintenance

of the appliance.

This appliance complies with the following

EC Directives: -73/23/EEC, 93/68/EEC-

Low Voltage Directive-89/336EEC -EMC

Directive.

■ Never allow children to use the

appliance unsupervised.

■ Do not use the appliance If the

supply cord is damaged or faulty.

■ If the supply cord is damaged, it must

be replaced by an approved LG

Electronics Service Agent to avoid a

hazard.

■ Always switch the vacuum cleaner off

before :

• changing the dust bag

• changing or cleaning the filters.

■ If no dustbag is inserted, the cover

cannot be closed. Please do not use

force!

■ Do not vacuum flammable or explosive

substances (liquids or gases).

■ Do not vacuum hot ash, embers etc.

nor sharp objects.

■ Do not vacuum water or other liquids.

■ Please make sure when using the

carrying starp that it is securely fitted.

■ The use of radio trans mitting devices

close to the appliance may interfere

the function of the appliance, input

power may be vary.

■ When you vacuum with an attachment

appliance that has a rotating brush

roller:

• do not reach into the running brush roller.

Connecting the flexible hose

Insert the hose holder (1) into the

suction opening.

When the hose (2) is to be disconnected

from the appliance, press the release

button (3) and pull the hose holder out

of the suction opening.

Assembling the tubes

• Telescopic tube (4)

- Hold spring latch (5)

- Pull out the tube to required length.

- Release spring latch to lock.

•

Metal tube (4)

- Connect tubes to each other.

• Elbow tube is for cleaning under the

sofa, table and bed easily. (23)

- Connect the elbow tube to the

flexible hose and, connect the

telescopic tube to the elbow tube.

(You can also connect the telescopic

tube to the flexible hose without the

elbow tube.)

- If you pull the spring latch(22), the

elbow tube is bended. (23)

- If you stretch the elbow tube, it is

returned to its position.

Using the cleaning head and

Accessory Nozzles

Fit the large cleaning head onto the end

of the tube.

• The 2 position head (6) is equipped

with a pedal (7) which allows you to

alter its position according to the type

of floor to be cleaned.

Hard floor position(tiles, parquet

floors...). slide on the lever to lower

the brush.

Carpet or rug position. slide on the

lever to lift brush up.

• This device (24) is used with the suction

hole for device protection mounted. For

the suction hole for device protection, its

front, side and upper side is enclosed

with a soft material in order to prevent

damage of the device.

Connect the suction hole for device

Information for your safety

How to Use

■

Do not expose vacuum cleaner to heat.

Do not vacuum fine dust.

•

Turbine brush nozzle

Slide the air control lever to the right

for long type carpet and to the left for

short type carpet.

Press the button on the rear side of

the nozzle to separate the air cover.

Use the dusting brush & crevice tool

to vacuum clean the brush and fan.

- Air adjustment(20)

- Cleaning turbine brush nozzle(21)
