LG V-C4243 HTU [5/8] Changing the dust bag

– 5 –

protection to the extension pipe for

length adjustment.

Remove dusts accumulated where the

floor surface of the suction hole for

device protection is dirty.

• Crevice Tool (8)

For vacuuming in those normally

inaccess- ible places i.e. reaching

cobwebs, or down the side of a sofa!

• Upholstery Nozzle (9)

For vacuuming upholstery,

mattresses, etc. The thread collectors

help to pick up the threads and fluff.

• Dusting brush (10)

For vacuuming picture frames

furniture outlines, books and other

uneven objects.

How to plug in and use

Pull out the mains lead to the desired

length and plug into the socket.

Adjusting the power level

• Electronic power control (11)

Suction capacity increases steplessly up

to MAX.

String the cleaner

When you have switched off and

unplugged the appliance, press on the

button (19) to automatically rewind the

cord.(depending on model)

• Use storage clip as shown when

storing the cleaner (12)

Changing the dust bag

The dustbag needs changing when the

cleaner is set to maximum power and

the cleaner head is off the floor but the

“bag full” indicator window (13) is

completely coloured red.

Even if the dustbag does not appear to

be full at this stage, it should be

changed.

It could be that a great deal of very fine

dust has clogged up the pores of the

dust bag.

• Turn off the appliance and unplug it.

• Remove hose.

• Open the cover (14)

Your appliance is equipped with either a

paper dust bag or a fabric dust bag (15)

• Push the lever forwards in the

direction of the arrow (16), and pull off

the full paper filter bag towards the

rear. Remove the bag and throw it

away.

• Insert the new paper filter bag into the

unit with the arrow pointing downwards

(17)

If your appliance is fitted with a

dust bag, empty it and replace it.

Note: as the appliance is fitted with a

safety device which checks that the bag

is in place you cannot close the lid if the

bag is not fitted correctly.

Cleaning the motor filter

The motor filter is situated inside the

appliance between the dust bag and

the motor. Each time that you change

the air outlet filter we advise you to

remove the motor filter (18) and to

clean it by tapping to remove the dirt

and then replacing it in the vacuum

cleaner.

Check that the appliance is correctly

plugged in and that the electrical socket

is working.

• Stop the appliance and unplug it.

• Check that the tubes, flexible hose

and cleaning tool are not blocked.

• Check that the dust bag is not full.

Replace it if necessary.

• Check that the air outlet filter is not

blocked. Replace it if necessary.

What to do if your appliance

does not work

What to do when the suction

performance reduces?
