INSTRUCTIONS FOR THE INSTALLER

The earth wire (yellow-green) should not be interrupted by any switches. The live wire is brown in colour (it goes out

from clamp L in the switchbox) should always be connected to the live wire in the mains.

The power cable should be placed so as not to exceed room temperature by 50 ° С at any point along it.

A power cable for two hobs should have a cross-section of at least 3 by 1.5 mm2, and for four hobs, 3 by 2.5 mm2.

Fig.8-8 /А and  g. 8-8 /В indicate the di erent types of connection, varying according to model and mains voltage.

This product complies with EU directive 2002/96/EC.

The crossed-out dustbin symbol on the appliance indicates that the appliance must be disposed of

separately from other domestic refuse at the end of its useful life. It must therefore be delivered to a waste

recycling center speci cally for electric and electronic equipment or returned to the retailer at the moment

of purchase of a new equivalent appliance.

The user is responsible for delivering the appliance to the appropriate collection center at the end of its

useful life. Failure to do so may result in a  ne, as provided for by laws governing waste disposal.

Di erential collection of waste products for eventual recycling, treatment and environmentally friendly disposal helps

reduce possible negative e ects on the environment and health, and also enables the materials making up the product

to be recycled.

For more detailed information on the available refuse collection systems, refer to the local Municipal Solid Waste disposal

centre or the shop where the product was purchased.

Producers and importers are responsible for ful lling their obligations as regards recycling, treatment and environmentally

friendly disposal by directly or indirectly participating in the collection system.

• • TECHNICAL MAINTENANCE AND SPARE PARTS

Before leaving the factory, all our products are con gured and tested by a quali ed, experienced professional with the

aim of ensuring optimal working conditions for them.

Original spare parts and accessories may be bought or ordered via a trade network or from authorised service centres.

Your may make an order using our information line at 0-800-500-514, or on the relevant section or our site, www.freggia.

com.

All repair and tuning must be carried out by a quali ed professional in accordance with Freggia’s requirements. Given the

above, we recommend always using authorised service centres (by phoning the support line on 0-800-500-514, free to

call from landlines within Ukraine), telling them your make, model and factory number.

All this information may be found on the factory information label, located on the back of the device, and on its packaging.

The information in question will enable the service centre agent to authorise calling out a repairman and to choose

necessary spare parts and accessories, and it guarantees timely and e ective service. We recommend writing down these

details here, so as to always have them to hand, or else to a x the sticker with your appliance’s details on it to the frame

on the instruction booklet cover.

The manufacturing  rm accepts no responsibility for any possible imprecision in this booklet due to misprints or

clerical errors. It reserves the right to make any changes that it considers necessary to its own products, without

a ecting the essential characteristics of functionality and safety.
