Features and Controls Compare the illustration CD with your engine to familiarize yourself with the location of various features and controls A Engine Identification Model Type Code B Spark Plug C Air Cleaner D Choke E Starter Cord Handle F Finger Guard G Throttle Control optional H Stop Switch optional I Fuel Tank and Cap optional J Oil Drain Plug If the oil level is low add the proper amount of oil Start the engine and make sure the warning light if equipped is not activated If the oil level is not low do not start the engine Contact an Authorized Briggs Stratton Dealer to have the the oil problem corrected Fuel Recommendations Fuel must meet these requirements Clean fresh unleaded gasoline A minimum of 87 octane 87 AKI 91 RON High altitude use see below Gasoline with up to 10 ethanol is acceptable CAUTION Do not use unapproved gasolines such as E15 and E85 Do not mix oil in gasoline or modify the engine to run on alternate fuels Use of unapproved fuels will cause damage to engine components which will not be covered under warranty To protect the fuel system from gum formation mix a fuel stabilizer into the fuel See Storage All fuel is not the same If starting or performance problems occur change fuel providers or change brands This engine is certified to operate on gasoline The emissions control system for this engine is EM Engine Modifications K Oil Fill High Altitude L Muffler Muffler Guard Spark Arrester optional Muffler Deflector optional At altitudes over 5 000 feet 1524 meters a minimum 85 octane 85 AKI 89 RON gasoline is acceptable To maintain performance high altitude adjustment is required Operation without this adjustment will cause decreased performance increased fuel consumption and increased emissions See an authorized Briggs Stratton Dealer for high altitude adjustment information Operation of the engine at altitudes below 2 500 feet 762 meters with the high altitude kit is not recommended Operation of the engine at altitudes below 2 500 feet 762 meters with high altitude adjustment is not recommended M Fuel Shutoff Operation Oil capacity see the Specifications section How To Add Fuel Figure 3 Oil Recommendations We recommend the use of Briggs Stratton Warranty Certified oils for best performance Other high quality detergent oils are acceptable if classified for service SF SG SH SJ or higher Do not use special additives Outdoor temperatures determine the proper oil viscosity for the engine Use the chart to select the best viscosity for the outdoor temperature range expected WARNING Fuel and Its vapors are extremely flammable and explosive Are or explosion can cause severe burns or death When Adding Fuel Turn engine off and let engine cool at least 2 minutes before removing the fuel cap Fill fuel tank outdoors or in well ventilated area Do not overfill fuel tank To allow for expansion of the fuel do not fill above the bottom of the fuel tank neck Keep fuel away from sparks open flames pilot lights heat and other ignition sources Check fuel lines tank cap and fittings frequently for cracks or leaks Replace it necessary If fuel spills wait until it evaporates before starting engine 1 Clean the fuel cap area of dirt and debris Remove the fuel cap A Figure 3 2 Fill the fuel tank B with fuel To allow for expansion of the fuel do not fill above the bottom of the fuel tank neck C 3 Reinstall the fuel cap Below 40 F 4 C the use of SAE 30 will result in hard starting How To Start The Engine Figure Above 80 F 27 C the use of 10W 30 may cause increased oil consumption Check oil level more frequently WARNING Rapid retraction of starter cord kickback will pull hand and arm toward engine faster than you can let go Broken bones fractures bruises or sprains could result How To Check Add Oil Figure 2 Before adding or checking the oil Place engine level Clean the oil fill area of any debris 1 Remove the dipstick A and wipe with a clean cloth 2 Insert the dipstick Do not turn or tighten 3 Remove the dipstick and check the oil level It should be at the top of the full indicator B on the dipstick 4 To add oil pour the oil slowly into the engine oil fill C Fill to point of overflowing 5 Replace and tighten the dipstick Low Oil Protection System if equipped Some engines are equipped with a low oil sensor If the oil is low the sensor will either activate a warning light or stop the engine Stop the engine and follow these steps before restarting the engine Make sure the engine is level Check the oil level See the How To Check Add OH section en When starting engine pull the starter cord slowly until resistance is felt and then pull rapidly to avoid kickback A WARNING Fuel and Its vapors are extremely flammable and explosive Are or explosion can cause severe burns or death When Starting Engine Ensure that spark plug muffler fuel cap and air cleaner if equipped are in place and secured Do not crank engine with spark plug removed If engine floods set choke if equipped to OPEN RUN position move throttle if equipped to FAST position and crank until engine starts 7
