1. INTRODUCTION

1.1 Congratulations on your purchase of this Kramer Electronics amplifier. Since 1981 Kramer has been dedicated

to the development and manufacture of high quality video/audio equipment. The Kramer line has become an

integral part of many of the best production and presentation facilities around the world. In recent years,

Kramer has redesigned and upgraded most of the line, making the best even better. Kramer’s line of

professional video/audio electronics is one of the most versatile and complete available, and is a true leader in

terms of quality, workmanship, price/performance ratio and innovation. In addition to the Kramer line of high

quality amplifiers, such as the one you have just purchased, Kramer also offers a full line of high quality

switchers, processors, interfaces, controllers and computer-related products. This manual includes

configuration, operation and option information for the VM-80V and VM-10AN distribution amplifiers.

1.2

A Word On Distribution Amplifiers

Distribution amplifiers are used to distribute one source to several acceptors for simultaneous recording or

monitoring of one source, with no discernible signal degradation. They vary in the number of inputs, looping

capability, programming capability, number of outputs, operating format, bandwidth and input/output coupling.

A good quality distribution amplifier amplifies the incoming signal, pre-compensates the signal for potential

losses (resulting from the use of long cables, noisy source, etc.) and generates several identical buffered and

amplified outputs.

1.3 Factors Affecting Quality of Results

There are many factors affecting the quality of results when signals are transmitted from a source to an acceptor:

Connection cables - Low quality cables are susceptible to interference; they degrade signal quality due to poor

matching and cause elevated noise levels. They should therefore be of the best quality.

Sockets and connectors of the sources and acceptors - So often ignored, they should be of highest quality,

since "Zero Ohm" connection resistance is the target. Sockets and connectors also must match the required

impedance (75 ohms in video). Cheap, low quality connectors tend to rust, thus causing flaws in the signal path.

Amplifying circuitry - Must have quality performance when the desired end result is high linearity, low

distortion and low noise operation.

Distance between sources and acceptors - Plays a major role in the final result. For long distances (over 15

meters) between sources and acceptors, special measures should be taken in order to avoid cable losses. These

include using higher quality cables or adding line amplifiers.

Interference from neighboring electrical appliances - These can have an adverse effect on signal quality.

Balanced audio lines are less prone to interference, but unbalanced audio should be installed far from any mains

power cables, electric motors, transmitters, etc. even when the cables are shielded.
