Technical Specifications
6
6 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VM-312 Multi-Format Distributor
CV COMP (YUV) Y/C AUDIO
INPUTS: 1 composite video
on an RCA
connector
1Vpp/75
1 component
video (Y, B-Y, and
R-Y) on RCA
connectors
1Vpp/0.7Vpp/75
1 s-Video on a 4p
connector
1Vpp/0.3Vpp/75
1 stereo
unbalanced on a
3.5mm mini jack
connector
4dBm/50k
OUTPUTS: 2 composite video
on RCA
connectors
1Vpp/75
2 component
video (Y, B-Y, and
R-Y) on RCA
connectors
1Vpp/0.7Vpp/75
2 s-Video on 4p
connectors
1Vpp/0.3Vpp/75
2 stereo
unbalanced on
3.5mm mini jack
connectors
4dBm/150
MAX. OUTPUT LEVEL: 1.8Vpp 21Vpp
BANDWIDTH (-3dB): 490MHz 450MHz 420MHz >100kHZ
DIFF. GAIN: 0.05%
DIFF. PHASE: 0.03 Deg.
K-FACTOR: <0.05%
S/N RATIO: 75dB 82dB
CROSSTALK (all
hostile):
–52dB @ 5MHz, YUV into CV -45dB video into
audio @ 15kHz
COUPLING: DC Input: AC; output:
DC
AUDIO THD + NOISE: 0.047% @ 1kHz
AUDIO 2nd HARMONIC: 0.001% @ 1kHz
POWER SOURCE: 12V DC, 130mA DC
DIMENSIONS: 21.5cm x 16.25cm x 4.36cm (8.45” x 6.39” x 1.72”), W, D, H.
WEIGHT: 1.2 kg. (2.65 lbs.) approx.
ACCESSORIES: Power cord
1 Specifications are subject to change without notice
