Kramer VM-4HDXL [10/12] Technical specifications

VM-4HDxl - Technical Specifications

5 Technical Specifications

INPUT:

1 SMPTE-259M / 292M / 424M serial video, 75Ω on a

BNC connector

OUTPUTS:

4 equalized and reclocked SMPTE-259M / 292M / 424M

outputs, 75Ω on BNC connectors

MAXIMUM DATA RATE (-3dB):

3Gbps

MAX. OUTPUT LEVEL:

800mVpp /75Ω

COUPLING:

POWER SOURCE:

5V DC, 380mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12.0cm x 7.1cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H.

WEIGHT:

0.3kg (0.66lbs) approx.

INCLUDED ACCESSORIES:

Power supply, mounting bracket

OPTIONS:

RK-3T 19” rack adapter

Specifications are subject to change without notice

For the most updated resolution list, go to our Web site at http://www.kramerelectronics.com
