Contents
ii
Tables
Table 1: Front Panel VS-41HD 4x1 HD/SD-SDI Switcher / DA 5
Table 2: Rear Panel VS-41HD 4x1 HD/SD-SDI Switcher / DA 5
Table 3: Machine # DIP-switch Settings
9
Table 4: Technical Specifications of the VS-41HD 4x1 HD/SD-SDI Switcher / DA
15
Table 5: Protocol Definitions
16
Table 6: Instruction Codes for Protocol 2000 17
