KRAMER: SIMPLE CREATIVE TECHNOLOGY
Installing the Room Controller
6
4.2 Defining the RC-63A and RC-63AL
The Kramer RC-63A is available as a 2 Gang wall plate (for Europe and the
USA). It features 6 front panel buttons designed in two groups; one group of 2
buttons, and another group of 4 buttons. Each group can be programmed
according to the user's requirements. The:
• RC-63A has the DISPLAY and SOURCES labels printed on the unit
• RC-63AL has LCD labels, letting you program the required group label, as
well as rolling text on the display
The RC-63A also includes:
• An analog volume control adjustment knob
• Two relays for the simplified and centralized control of room functions (such
as lighting, closing blinds, screen settings, and so on)
• An IR output, a bidirectional RS-232 port, and two K-NET ports
• An IR-learner for the customized control of external sources, memorizing the
IR commands from different remote transmitters
A USB port is included for programming the RC-63A via a computer.
Table 4
defines the RC-63 and RC-63AL.
