FC-32 - Technical Specifications

5 Technical Specifications

INPUTS:

1 DVI-D, 1.2Vpp on a Molex 24-pin (F) connector; DDC

signal 5Vpp (TTL)

OUTPUTS:

1 VGA or YPbPr on a 15-pin HD (F) connector; YPbPr is

with bi-level sync

RESOLUTION:

Up to WUXGA, 1080p

VESA standard timing is supported. When the input timing

does not comply to this standard, the FC-32 may not display

correctly (for example, the pixel clock from a GeForce 6600

graphics card operating at 1600x1200 resolution is at 140MHz

instead of at 162MHz)

CONTROL:

Switch for RGB/YPbPr selection

POWER CONSUMPTION:

5V DC, 570mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H

WEIGHT:

0.3kg (0.7lbs)

INCLUDED ACCESSORIES:

Power supply

OPTIONS:

RK-3T 19” rack mount

Specifications are subject to change without notice at http://www.kramerelectronics.com
