TP-46N - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix
Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;
GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;
GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and
GROUP 11: Sierra Products.
Thank you for purchasing the Kramer TOOLS TP-46N Component/UXGA/Audio
Receiver, that uses existing UTP cabling to create an efficient, fast and uncluttered
environment for:
Presentation and multimedia applications
Long-range graphics distribution for schools, hospitals, security, and stores
Security and military applications
Содержание
- User manual 1
- Contents 3
- Figures 3
- Introduction 4
- Achieving the best performance 5
- Getting started 5
- Safety instructions 5
- Recycling kramer products 6
- Overview 7
- About the power connect feature 8
- Shielded twisted pair stp unshielded twisted pair utp 8
- Defining the tp 46n 9
- Figure 1 defines the tp 46n component uxga audio receiver 9
- Connecting a component uxga audio distribution system 10
- Connecting the system in uxga mode 11
- Connecting the system in component video mode 13
- Connectors 15
- Note that the cable ground shielding must be connected soldered to the connector shield 15
- This section defines the cat 5 pinout using a straight pin to pin cable with rj 45 15
- Wiring the cat 5 line in line out rj 45 connectors 15
- Technical specifications 16
