The TP-46N is a twisted pair receiver for component video (YUV) or computer

graphics video and unbalanced stereo or S/PDIF audio signals. The TP-45/

TP-45RC transmitters convert audio and video to a twisted pair signal and the

TP-46N converts the twisted pair signal back into audio and video signals.

By selecting the required video input signal, the TP-45 or TP-45RC with the

TP-46N can constitute either a component video (Y, CB/PB, CR/PR) or a UXGA

video–audio transmitter/receiver system:

The term UXGA used throughout this user manual implies VGA resolutions up to and

exceeding UXGA.

The TP-46N does not convert the video signal format. Thus computer graphics sources must

be routed to computer graphics outputs. Similarly, component video sources must be routed to

component video outputs.

 If UXGA is selected, the TP-45 or TP-45RC receives a UXGA (and audio)

signal and transmits it over the CAT 5 cable to the UXGA output on the

TP-46N receiver

 If component video is selected, the component video signal is transmitted

over the CAT 5 cable to the COMP outputs on the TP-46N receiver

 The analog audio or S/PDIF (digital audio)—as selected via the audio

SELECT button—is transmitted together with the video signal over the CAT

5 cable to the TP-46N receiver

The audio signal is distributed simultaneously to the analog or digital audio

outputs.

Additional TP-46N units can be connected via the TP-46N LINE OUT CAT 5

connector, to extend the range of the output signals.

You can connect up to three additional TP-46N units, adding a total cable length of up to 300

meters. The video quality may be reduced if further units are connected.

The TP-46N Component/UXGA/Audio Receiver features:

 YUV output on 3 RCA connectors and a computer graphics output on a

15-pin HD (F) connector

 Digital audio output (S/PDIF) on an RCA connector and a stereo analog

output on a 3.5mm mini jack
