TP-46N - Connecting a Component/UXGA/Audio Distribution System

4.1 Connecting the System in UXGA Mode

To configure a TP-46N component/UXGA/audio distribution system in the UXGA

mode (using up to 300ft (100m) of UTP cabling), as shown in Figure 2, do the

following:

1. On the TP-45 or TP-45RC, connect the following:

 An UXGA source (for example, the graphics card on a laptop) to the

UXGA 15-pin HD (F) connector

 An analog audio source to the ANALOG AUDIO 3.5mm mini jack (or a

digital audio source to the S/PDIF RCA connector), for example, using

a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) with audio jack to

VGA 15-pin HD (M) with audio jack)

Cables are not supplied. The complete list of Kramer cables is on our Web site at

http://www.kramerelectronics.com.

2. On the TP-45, use the SELECT buttons as follows:

 Press the video SELECT button to choose the UXGA input

 Press the audio SELECT button to choose S/PDIF

 Release the audio SELECT button to choose analog audio

3. On the TP-45RC, use the SELECT buttons as follows:

 Momentarily press the video SELECT button. The UXGA LED lights

when the UXGA input is selected

 Momentarily press the AUDIO SELECT button to toggle between the

S/PDIF and analog audio inputs

The analog audio LED lights when analog audio is selected.

4. On the TP-46N, connect the following:

 The UXGA OUT 15-pin HD (F) connector to the UXGA acceptor (for

example, a display)

 The ANALOG AUDIO 3.5mm mini jack to the analog audio acceptor

(for example, speakers)

Alternatively, you can connect a digital audio acceptor to the S/PDIF RCA

connector, or you can connect both.
