PT-580T/TP-580T/TP-580R - Technical Specifications
17
17
7 Technical Specifications
TP-580T
TP-580R
INPUTS:
1 HDMI connector
1 RJ-45 connector
OUTPUTS:
1 RJ-45 connector
1 HDMI connector
PORTS:
1 IR on a 3.5mm mini jack
(for emitter or sensor)
1 RS-232 on a 9-pin D-sub
connector
1 IR on a 3.5mm mini jack (for
emitter or sensor)
1 RS-232 on a 9-pin D-sub
connector
BANDWIDTH:
Supports up to 3.4Gbps bandwidth per graphic channel
RS-232 BAUD RATE:
115200
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
12V DC, 275mA
12V DC, 430mA
DIMENSIONS:
18.8cm x 11.4cm x 2.4cm (7.4" x 4.5" x 1.0") W, D, H
WEIGHT:
0.6kg (1.4lbs)
INCLUDED ACCESSORIES:
2 Power supply units 12V/1.25A
OPTIONS:
RK-T2B 19” rack mount; Kramer external IR sensor (P/N: 95-
0104050), Kramer IR emitter cable (P/N: C-A35/IRE-10); Kramer
BC−HDKat6a cable
Specifications are subject to change without notice
Go to our Web site at http://www.kramerelectronics.com to access the list of resolutions
PT-580T
INPUTS:
1 HDMI connector
OUTPUTS:
1 RJ-45 connector
BANDWIDTH:
Supports up to 3.4Gbps bandwidth per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
5V DC, 575mA
DIMENSIONS:
6.2cm x 5.2cm x 2.4cm (2.4" x 2.1" x 1") W, D, H
WEIGHT:
0.14kg (0.3lbs)
INCLUDED ACCESSORIES:
5V DC power supply
OPTIONS:
19” RK-4PT rack adapter; Kramer BC−HDKat6a cable
Specifications are subject to change without notice
Go to our Web site at http://www.kramerelectronics.com to access the list of resolutions
