PT-580T/TP-580T/TP-580R - Overview

3 Overview

This section describes the PT-580, TP-580T and TP-580R features.

3.1 TP-580T and TP-580R Overview

The TP-580T and TP-580R are a high-performance, HDBaseT technology twisted

pair transmitter and receiver for HDMI, bidirectional RS-232 and IR signals. The

TP-580T converts the HDMI signal, RS-232 and IR input signals to a twisted pair

signal. The TP-580R converts the twisted pair signal back into HDMI, RS-232, and

IR signals.

The TP-580T and the TP-580R can form a transmission and reception system

either together or each device separately with another certified HDBaseT device.

For example, the transmitter and receiver system can be composed of the TP-580T

that connects to the Kramer TP-580R to form a transmitter receiver pair.

The TP-580T transmitter and TP-580R receiver feature:

 A bandwidth of up to 10.2Gbps (3.4Gbps per graphic channel), supporting

4K resolution

 A range of up to 70 meters (230 feet)

For optimum range and performance using HDBaseT™, use Kramer's

BC−HDKat6a cable. Note that the transmission range depends on the

signal resolution, source and display used. The distance using

non−Kramer CAT 6 cable may not reach these ranges.

 HDBaseT™ technology

 HDTV compatibility and HDCP compliance

 HDMI support - HDMI (deep color, x.v.Color™, lip sync, HDMI

uncompressed audio channels, Dolby TrueHD, DTS−HD, CEC, 2k, 4k, 3D)

 EDID pass through, passes EDID/HDCP signals from the source to the display

 Bidirectional RS-232 interface - commands and data can flow in both

directions via the RS−232 interface, allowing status requests and control of

the destination unit
