PT-580T/TP-580T/TP-580R - Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP
5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP
7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer PT-580T or TP-580T or TP-580R
transmitter/receiver pair, which is ideal for the following typical applications:
Projection systems in conference rooms, boardrooms, auditoriums, hotels
and churches, production studios
Rental and staging
Note that PT-580T, TP-580T and TP-580R are purchased
separately, and can be connected to other HDBaseT certified
transmitters and receivers, respectively.
