PT-101HDCP - Overview

3 Overview

The PT−101HDCP is a line driver/repeater for DVI−D video signals that extends

the standard transmission range of standard DVI distances from 5m to up to 10m

(16.4ft to up to 32.8ft). The unit reclocks and equalizes the signal enabling multiple

units to be cascaded. It supports the DDWG DVI 1.0 standard and has two DVI-I

connectors, that are compatible with all types of DVI cables.

The PT-101HDCP can be powered by an external power supply, or directly—from

DVI connectors on Kramer Scalers, as well as from some desktop DVI cards—

without requiring an external power supply

Note that only the digital signal (DVI-D) is available on the DVI connector.

More specifically the PT-101HDCP features:

 A maximum data rate of 6.75Gbps (2.25Gbps per graphic channel)

 HDTV compatibility

 HDCP compliance

 HDMI support for HDMI Compressed Audio Channels

 Kramer Equalization & re-Klocking™ Technology that rebuilds the digital

signal to travel longer distances

 Power via AC adapter or by DVI signal

 Double the DVI range (resolution dependent) from approximately 16ft (4.9m)

to approximately 32ft (9.8m)

 Ultra-Compact Pico TOOLS™ where four units can be rack mounted

side−by−side in a 1U rack space with the optional RK−4PT rack adapter
