8 690T, 690R - Technical Specifications

5 Technical Specifications

690T 690R

INPUTS: 2 SDI/HD−SDI/3G-SDI on BNC

connectors

2 LC optical connectors

OUTPUTS: 2 LC optical connectors 2 SDI/HD−SDI/3G-SDI on BNC

connectors

BANDWIDTH: Supports up to 3Gbps bandwidth for each input

FIBER OPTIC

EXTENSION:

Up to 10km (>6.2 miles) for 3G-SDI

INPUT CABLE

EQUALIZATION

200m for SDI, 100m for 3G-SDI

FIBER-OPTIC

CONNECTION:

Dual single mode fiber (9/125) over LC connectors

POWER SOURCE: 5V DC, 480mA 5V DC, 350mA

OPERATING

TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE

TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY: 10% to 90%, RHL non-condensing

DIMENSIONS: 6.2cm x 5.2cm x 2.4cm (2.4" x 2.0" x 0.9") W, D, H

WEIGHT: 0.14kg (0.31lbs) approx each

ACCESSORIES: 1 Power supply

OPTIONS: RK-4PT rack adapter

Specifications are subject to change without notice at http://www.kramerelectronics.com
