8 VA-4H - Operating the VA-4H

6 Operating the VA-4H

To set the EDID source for each channel as illustrated in the example in Figure 3:

1. Press and hold the CAPTURE pushbutton. The indicator LEDS illuminate in

a cycle as follows:

MONITOR, lower green LED

DEFAULT, upper red LED

PASS, both LEDS together.

2. Release the pushbutton at the desired setting.

The setting is saved in non-volatile memory.

Notes:

• DEFAULT and MONITOR settings do not support HDCP key exchange.

For the display to work properly with HDCP encryption, the VA-4H must be

set to PASS

• If an EDID is captured the MONITOR LED flashes slowly

• If an EDID is not captured, the DEFAULT LED flashes quickly and the

default EDID is loaded

• When exchanging a display, refresh the source by disconnecting and

reconnecting the HDMI cable between the source and the device input
