Kramer VS-40FW [11/13] Table 2 includes the technical specifications

Technical Specifications

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications

PORTS:

of the VS-40FW

4 bidirectional IEEE 1394b 800Mbps (S800) ports

TRANSFER RATE: 100/200/400/800Mbps

STANDARDS:

(S800, S400, S200, S100)

IEEE 1394-1995, IEEE P1394a, IEEE P1394b

Fully supports the provisions of the IEEE P1394b Revision 1.33+ at 1 Gigabit

signaling rates;

Fully supports the provisions of the IEEE 1394-1995 Standard for High

Performance Serial Bus and the P1394a Supplement;

Fully interoperable with FireWire™ and i.LINK™ implementation of IEEE Std 1394;

Provides three fully backward compatible (1394a 2000 fully compliant) bilingual

P1394b cable ports at up to 800 Megabits per second (Mbits/s);

Fully compliant with OpenHCI requirements;

Provides three P1394b Fully Compliant Cable Ports at 100/200/400/800 Megabits

per Second (Mbits/s);

Full P1394a support includes: Connection Debounce, Arbitrated Short Reset,

Multispeed Concatenation, Arbitration Acceleration, Fly-By Concatenation, Port

Disable/Suspend/Resume;

Extended Resume Signaling for Compatibility with Legacy DV Devices

POWER SOURCE: 12V DC, 1A

DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H

WEIGHT: 0.3kg (0.67lbs) approx.

ACCESSORIES: Power supply (12V, 2.1A), mounting bracket, 1 0.9m (3ft) 9-pin FireWire® cable

OPTIONS: Adapting cables

, RK-3T 19" rack adapter, 0.9m (3ft) 9-pin FireWire® cables

1 Specifications are subject to change without notice

2 Legacy FireWire speeds

3 For details, refer to our Web site at

http://www.kramerelectronics.com

4 C-FM9/FM9-3
