KDS-EN3, KDS-DEC3 - Connecting the Product
5 Connecting the Product
Always switch off the power to each device before connecting it to your
KDS-EN3, KDS-DEC3. After connecting your KDS-EN3, KDS-DEC3,
connect its power and then switch on the power to each device.
5.1 Connecting the KDS-EN3
To connect the KDS-EN3 as illustrated in the example in Figure 3 you must:
1. Connect the LAN 1 RJ-45 connector to a network cable.
2. Connect an HDMI source (for example, a KDS-MP1) to the HDMI IN
connector.
The following connections are optional:
3. Connect the PC (Out Local) 15-pin HD connector to a VGA acceptor (for
example, a display).
4. Connect the HDMI (Out Local) connector to an HDMI acceptor (for example,
a display).
5. Connect the RS-232 9-pin D-sub connector to a computer serial controller
(for example, a PC) using a standard straight-through cable.
6. Connect an audio acceptor (for example, an amplifier) to the AUDIO OUT
3.5mm mini jack connector.
7. Connect an unbalanced stereo audio source (for example, a DVD) to the
AUDIO IN 3.5mm mini jack connector.
