![Kramer KDS-DEC3 [17/25] Validating your kds en3 setup](/views2/1153360/page17/bg11.png)
14
KDS-EN3, KDS-DEC3 - Validating Your KDS-EN3 Setup
6 Validating Your KDS-EN3 Setup
After connecting your KDS-EN3/KDS-DEC3 units, we recommend you validate
your connection setup, network discovery, and the quality of your audio and video
sources before you continue.
6.1 Description of LEDs
The network connector LEDs and power LED on your KDS-EN3 units provide
information that can help you troubleshoot your Kramer product.
Network Connector
The network connectors on your Kramer Encoder and Decoder unit use indicator
lights (LEDs) to provide information on the network activity and presence. The
following describes the different network connector LEDs.
LED color
Network activity
Network presence
No LED (black)
No data transfer in progress or no
network detected
No communication
established
Green (flashing)
Data transfer in progress
—
Orange
—
Network communication
established
Encoder/Decoder
The power LED (ON) on your Kramer Encoder or Decoder unit provides
information on the status of your unit. The following describes the power LED on
your KDS-EN3/KDS-DEC3 unit.
LED color
Encoder
Decoder
No LED (black)
Unit isn’t powered
Unit isn’t powered
Green/Red (flashing)
Unit is initializing
Unit is initializing
Green
Unit is ready
Unit is ready
Green (flashing)
Encoding and streaming
Decoding network stream
Red (flashing)
No valid audio/video input signal
detected
Unit isn’t in use
Red
Fatal error detected
Fatal error detected
Amber
Unit reset to factory default.
Unit requires maintenance
Unit reset to factory default.
Unit requires maintenance
Amber (flashing)
Configuring or updating
firmware
Configuring or updating
firmware
