The Kramer RK-19 Under-the-table Brackets

Congratulations on purchasing your Kramer metal RK-19 under-the-table brackets for

installing 19" 1U machines underneath a wooden table or podium top. The RK-19 is suitable

for all types of Kramer 19” 1U machines, and is sturdy, cost-effective and easy to install.

The RK-19 consists of two metal brackets which are attached to a Kramer 19” 1U machine via

the 12 machine screw holes and to the table via the six rim screw holes.

Figure 1: RK-19 Under-the-table Brackets

Installing RK-19

To install the RK-19:

• Attach the RK-19 brackets to the sides of the Kramer machine

• Fix the RK-19 with the machine under the table

Attaching the Brackets

You can attach the RK-19 brackets to all types of Kramer 19” 1U Kramer machines, as follows:

1U 19” Machine Size/Type Screw locations (shown with an arrow)

19-inch (W), 7-inch (D) 1U (H)/Aluminum

(four screws on each size)

1U 19” Machine Size/Type Screw locations (shown with an arrow)

19-inch (W), 9-inch (D) 1U (H)/Aluminum

(four screws on each size)

19-inch (W), 7-inch (D) 1U (H)/Metal

(two screws on each size)

19-inch (W), 9-inch (D) 1U (H)/Metal

(two screws on each size)
