Kramer RK-19 [2/2] Installation instructions

Fixing the RK-19 with the machine under the table

1. Place the unit to the underside of the table and mark the correct location.

2. Insert the six 4.2X16 wood screws into the six rim screw holes (three on each side) and fix

the RK-19 to the table.

Figure 2: RK-19 Installed under a Table

2BSpecifications

DIMENSIONS: Each bracket:

4.4cm x 22cm x 5.7cm (1.7” x 8.7” x 2.2”) W, D, H

Space between rim holes: 10cm (3.9”)

WEIGHT: 0.35kg (0.8lbs) approx. (for the pair)

ACCESSORIES: 8 M3x8 screws; six 4.2X16 screws

KRAMER ELECTRONICS LTD.

Installation

Instructions

MODEL:

RK-19

Under-the-table Brackets
