5 Mounting the Devices on the Rack Adapter

The RK-6PS underside includes a set of screw holes that are suitable for the

mounting of devices of different sizes (see Section 4.1).

To mount the devices on the RK-6PS, as illustrated in Figure 1, do the following:

1. Place the first device on the rack (for example, the Kramer 907xl).

2. Hold both the 907xl and the RK-6PS with your hands and turn them upside

down.

3. Insert and the appropriate amount of screws through the holes on the

RK-6PS that correspond to the holes on the underside of the 907xl, using the

M3x5 screws supplied with the device (as illustrated in Figure 2).

4. Tighten the screws.

5. Rotate the RK-6PS horizontally with the device connected.

6. Place the next device (for example, the Kramer FC-50) alongside the device

that is already mounted.

7. Repeat steps 2 to 6 for each other unit.
