Kramer MTH-1 [2/2] Installation instructions

Note that the MTH-1 is attached to the rear side of the display using the screws

that were supplied with the display (either screwed into its rear side or in a

separate bag).

7. Attach the MTH-1 to the rear side of the display using the screws that were supplied

by the display manufacturer.

The location of the screw-holes, as well as the number of screws used for each display may vary,

depending on the manufacturer.

Figure 5: Attaching the MTH-1 to the Rear Side of the Display

KRAMER ELECTRONICS LTD.

Installation

Instructions

MODEL:

MTH-1

VESA Adapter Plate
