Kramer GALIL 4-CO [15/18] Technical specifications
![Kramer GALIL 4-CO [15/18] Technical specifications](/views2/1154001/page15/bgf.png)
12
Galil 4-CO - Technical Specifications
6 Technical Specifications
Galil 4-CO
Audio and Power
DESCRIPTION:
2−Way open-back ceiling speakers
FREQUENCY RESPONSE:
60Hz to 20kHz @ -10dB
80Hz to 20kHz @ ±3dB
WOOFER:
4” (103mm) polypropylene with rubber surround
TWEETER:
0.5” (13mm) Mylar
IMPEDANCE:
8Ω (transformer tap in off position)
TRANSFORMER TAPS:
70V – 15W / 7.5W / 3.7W / Off (Lo-Z)
100V – 15W / 7.5W / Off (Lo-Z)
SENSITIVITY:
83dB SPL, 1W@1m
MAX SPL:
Continuous: 95dB
Peak: 98dB
POWER HANDLING:
15W RMS
40W continuous program
CROSSOVER FREQUENCY:
13kHz
COVERAGE ANGLE:
104
DIRECTIVITY FACTOR (Q):
8, averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI):
9dB averaged 1kHz to 10kHz
INPUT CONNECTOR:
Terminal block
Shipping and Installation
MATERIALS:
Frame, aluminum grille, safety cord attached to
grille
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER:
0.95kg (2.09lbs) approx.
SHIPPING WEIGHT (FOR PAIR):
2.6kg (5.73lbs) approx.
DIMENSIONS:
External diameter: 16.7cm (6.57"); cutout diameter:
13.9cm (5.47")
INSTALLATION CLEARANCE:
Mounting depth: 6.82cm (2.7”)
INCLUDED ACCESSORIES:
Cutout template
COLORS:
Available in white
Specifications are within a 10% tolerance and are subject to change without notice at
http://www.kramerelectronics.com
