Galil 4-CO - Installing the Open-back Ceiling Speakers

5 Installing the Open-back Ceiling Speakers

This section explains how to install the Open-back ceiling speakers, that is:

 Choosing the best place to locate your speakers (see Section 5.1)

 Cutting the ceiling tile (see Section 5.2)

 Installing the speakers (see Section 5.3)

 Array installation general guidelines (see Section 5.4)

 Painting the speakers (see Section 5.5)

5.1 Choosing the Best Location

Ideally, locate the speakers above the main listening area. Before doing so, be

sure that:

 The desired location is free of obstructions, such as electrical piping, AC

ducts or water lines, and so on

 There is enough space behind the mounting surface for the speakers

 The rear side of the speaker is not blocked by wall studs or other objects
