Type 4-stroke, vertical cylinder, air-cooled diesel engine

No. of Cylinders 1

Bore x Stroke (mm) 78 x 67

Displacement (litres) 0.320

Continuous Rated Output

r/min

-1

3600

HP SAE 5.8

kW 4.3

PS 5.9

Max Rated Output

r/min

-1

3600

HP SAE 6.4

kW 4.8

PS 6.5

High Idling r/min

-1

3800

Dry Engine Weight

with Electric Start (lbs/kg) 90.4 / 41

Dry Engine Weight

without Electric Start (lbs/kg) 79.4 / 36

Cooling System Forced Air by Flywheel Fan

Lubrication System Forced lubrication with Trochoid Pump

Starting System Electric Start / Recoil Start

Dimensions (inches/mm)

Length x Width x Height 14.9 / 378 x 16.6 / 422 x 17.8 / 453

Engine Oil Pan Capacity

Dipstick Upper Limit 1.11 qt / 1.05 litres

Dipstick Lower Limit 0.69 qt / 0.65 litres

Fuel Tank Capacity (recommended) 2.85 qt / 2.7 litres

YANMAR L70V

4.8kW (6.4hp) @

3600r/min

-1
