Hitachi DS 14 DVB 2 [16/96] English

English

11. Using the hook

CAUTION:

䡬 When using the hook, pay sufficient attention so

that the main equipment does not fall. If the tool

falls, there is a risk of accident.

䡬 Do not attach the tip tool except phillips bit to the

tool main unit when carrying the tool main unit with

the hook suspended from a waist belt.

Injury may result if you carry the equipment

suspended from the waist belt with sharp tipped

components such as drill bit attached.

The hook can be installed on the right or left side and

the angle can be adjusted in 5 steps between 0° and

80°.

(1) Operating the hook

(a) Pull out the hook toward you in the direction

of arrow (A) and turn in the direction of arrow

(B) (Fig. 12).

(b) The angle can be adjusted in 5 steps (0°, 20°,

40°, 60°, 80°).

Adjust the angle of the hook to the desired

position for use.

(2) Switching the hook position

CAUTION:

Incomplete installation of the hook may result in

bodily injury when used.

(a) Securely hold the main unit and remove the

screw using a slotted head screwdriver or a coin

(Fig. 13).

(b) Remove the hook and spring (Fig. 14).

securely fasten with screw (Fig. 15).

NOTE:

Pay attention to the spring orientation. Install the

spring with larger diameter away from you (Fig. 15).

(3) Using the bit holder (Hook with bit holder)

䡬 Installing the bit

Slide the bit from the side in the direction of

Fig. 16, and then insert firmly until the groove

on the bit locks in the protruded section of the

hook.

䡬 Removing the bit

Securely hold the main unit and pull out the bit

by holding the tip with your thumb (Fig. 17).

CAUTION:

䡬 The bit may come loose from the hook and cause

bodily injury when reversing the direction of the

bit as shown in Fig. 16 or when using the driver

with the bit stored incomplete.

䡬 Only Hitachi STANDARD ACCESSORIES phillips bit

(No. 2 × 55L; Code No. 318236) may be used. Do

not use other bits since they may come loose.

(4) Using as an auxiliary light (Hook with light)

(a) Press the switch to turn off the light.

If forgotten, the light will turn off automatically

after 15 minutes.

(b) The direction of the light can be adjusted within

the range of hook positions 1 - 5 (Fig. 18).

䡬 Lighting time

AAAA manganese batteries: approx. 15 hrs.

AAAA alkali batteries: approx. 30 hrs.

CAUTION:

Do not look directly into the light.

Such actions could result in eye injury.

(5) Replacing the batteries

(a) Loosen the hook screw with a phillips-head

screwdriver (No. 1) (Fig. 19).

Remove the hook cover by pushing in the

direction of the arrow (Fig. 20).

(b) Remove the old batteries and insert the new

batteries. Align with the hook indications and

position the plus (+) and minus (–) terminals

correctly (Fig. 21).

with the protuberance of the hook cover, press

the hook cover in the direction opposite to that

of the arrow shown in Fig. 20 and then tighten

the screw.

Use commercially available AAAA batteries

(1.5 V).

NOTE:

Do not tighten the screw excessively. Such action

could strip the screw threads.

CAUTION:

䡬 Failure to observe the following can result in battery

leakage, rust or malfunction.

Position the plus (+) and minus (–) terminals

correctly.

Replace both batteries at the same time. Do not mix

old and new batteries.

Remove exhausted batteries from the hook

immediately.

䡬 Do not discard batteries together with normal trash

and do not throw batteries into fire.

䡬 Store batteries out of the reach of children.

䡬 Use batteries correctly in accordance with the battery

specifications and indications.

MAINTENANCE AND INSPECTION

1. Inspecting the tool

Since use of as dull tool will degrade efficiency and

cause possible motor malfunction, sharpen or

replace the tool as soon as abrasion is noted.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure

that they are properly tightened. Should any of the

screws be loose, retighten them immediately. Failure

to do so could result in serious hazard.

3. Cleaning on the outside

When the driver drill is stained, wipe with a soft

dry cloth or a cloth moistened with soapy water.

Do not use chloric solvents, gasoline or paint thinner,

for they melt plastics.

4. Storage

Store the driver drill in a place in which the tempera

ture is less than 40°C and out of reach of children.

5. Service parts list

CAUTION:

Repair, modification and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized

Service Center.

This Parts List will be helpful if presented with the

tool to the Hitachi Authorized Service Center when

requesting repair or other maintenance.

In the operation and maintenance of power tools,

the safety regulations and standards prescribed in

each country must be observed.

01Eng_DS9DVB2_EE 08/4/16, 17:3215
