Автофон S-Маяк 5.x [10/44] Main operating modes
![Автофон S-Маяк 5.x [10/44] Main operating modes](/views2/1157998/page10/bga.png)
10
AutoFon SE-Mayak
MAIN OPERATING MODES
G - GPS/GLONASS-coordinates detection
The device determines location by satellites and sends a message
with the exact coordinates in a format specied by the conguration
command: SETUP= (parameter 8, page 20). Coordinates are either
in the form of numerical data or hyperlinks to dierent map servers
(Google Maps and Yandex.Maps). Additional parameters (date and
time positioning, speed, etc.) can also be delivered within the message.
S - GSM-coordinates detection mode
The device sends an SMS-message with IDs of four nearby GSM base
stations, level of signal strength from the current GSM base station,
the device’s temperature, battery charge and operating mode. This
mode is used when it is not necessary to determine exact coordinates.
F - Standby mode
The most economical operation mode. The device is activated by
set alarm time, turns the GSM-module on and waits SMS- messages.
After receiving the command, the device executes it. If there is no
command, the device starts hibernating until the next session.
To avoid SIM card blocking due to long inactivity, note that it
is impossible to set «Alarm T2» in F mode!
A - audio control mode
Within each activation set in alarms «Alarm Clock T1/T2», the
device will call admin and turn built-in microphone on to bug
the area around. Maximal audio monitoring time can be set in
command SETUP= (parameter 5 p. 21). There will be three attempts
(with an interval of 1 minute between each of them). After
nishing, the device will stay online for 5 more minutes to wait for
an SMS-command or a call.
The device can operate either in one mode or in a combination of
several (up to 5) modes with one «alarm clock» each.
MAIN OPERATING MODES
