Автофон S-Маяк 5.x [31/44] Information sms parameters description
![Автофон S-Маяк 5.x [31/44] Information sms parameters description](/views2/1157998/page31/bg1f.png)
English
Output channel indicator
Battery charge and temperature
Mode active (online) or interval (sleep) онлайн или спящий
Receiving command notification.
Current object speed at the time of positioning.
Horizontal and vertical coordinates accuracy setting.
Without possible signal reflection
Accelerometer settings (page 28)
. First number corresponds to the
action to be detected, second - the reaction on the action detection.
See Parameters #14, #15 page. 23
AutoFon SE-Mayak v6.1a
04-03-2012 13:45:04
Command OK. Wait.
Sat: 4 at 47s.
N55 52.7213
E037 36.1908
http://m.maps.yandex.ru/
?l=maps&ll=037.
143318,55.778838&pt=
037.143318,55.778838&z=13
GSM -68dB
MCC: 250 MNC: 001
LAC: 17D5 17D5 0321 0321
CID: 0F55 0F52 42EB 42EE
Speed: 73 км/ч
Altitude: 177 м
Accur: 10 м
1: +79037676045
IMEI: 359231039333995
SETUP=1025561721
011119111000000
i1=internet.mts.ru
i2=176.9.114.139.20102
i3=30
GPRS статус=1/0/0
FLASH:98304/0/0
Т1: 05-03-2012 12:00,01D,F
T2: 12-03-2012 15:30,07D,G
Sensor=1/1 (move)
External power: off
Output channel on.
Bat: 6.16 V (82%) Т: +34 °С
Mode: sleep
sms#11
Altitude from see level
GPS-coordinates.
Can be displayed in three formats:
• Degrees
• Degrees minutes seconds
• Degrees minutes.
Coordinates format can be set in SETUP=parameter 8 (page 18).
Received coordinates can be typed in map services search line
to see location point on the graphical or satellite map.
Information SMS Parameters Description
GPRS setting: Ask operator for APN-address
IP-address and monitoring port, where data are sent by GPRS
Interval to send packets to monitoring server via GPRS
Technical information about GPRS connection status and black box flash
