11
AutoFon SE-Mayak
COMMANDS TO CONTROL THE DEVICE
The device control is performed by sending SMS-commands to the
SIM card installed in it. At the beginning of each SMS-message the
password should be typed (4 digits and separator - «comma»).
It is not case sensitive. Additional symbols including «Space» aren’t
allowed. SMS-messages with an incorrect password or non-Latin
letters are not responded.
If several SMS-messages are sent, AutoFon SE-Mayak will only pay
attention to the last one. If you want to send several messages, do it
consistently, one by one, waiting for an SMS- conrmation for each
command. After receiving and executing commands, the device
stays online for the time set in setup, waiting for the next possible
command.
If it was not possible for AutoFon SE-Mayak to sent an SMS (probable
causes being no GSM network, no money on the SIM card), it will
make additional attempts and then it will return to set mode and
send these SMS-messages when possible.
All parameters and settings are stored in nonvolatile memory,
thus they do not change because of the replacement of
batteries or SIM-card.
Type your four-digit password instead of the word «password»
COMMANDS TO CONTROL THE DEVICE
