6
AutoFon SE-Mayak
command, the device starts hibernating until the next session.
A - audio control mode
Within each activation set in alarms «Alarm Clock T1/T2», the device
will call admin and turn built-in microphone on to bug the area
around. Maximal audio monitoring time can be set in command
SETUP= (parameter 5 p. 21). There will be three attempts (with an
interval of 1 minute between each of them). After nishing, the device
will stay online for 5 more minutes to wait for an SMS-command or
a call.
If this mode does not satisfy requirements AutoFon SE-Mayak can
also work in active mode and respond immediately, the battery life
in this case is lasts up to 10 days. When choosing this mode, we rec
-
ommend connecting to an external power source. Keep in mind
that during active mode the device can be easily detected
by GSM scanners.
To set the mode use your cell phone by sending commands in the
form of SMS-messages. The message should include password and
command. (read more on page 14). According to the parameters in
the message activation interval is thus set.
AutoFon SE-Mayak determines its position by GPS and sends it to
the owner via SMS or to the monitoring server in GPRS packets. Apart
from coordinates the device also sends LBS information. This infor
-
mation can help to determine the location without satellites’ connec-
tivity. Furthermore, SMS displays the current speed and the direc-
tion of movement. service information in the message includes date
and time of activation, battery charge, temperature inside the device,
mode, the number of satellites being found, GSM signal strength lev
-
el, the time it took to determine the coordinates, the number of sent
SMS- messages, and other useful information.
AutoFon SE-Mayak has a microphone that allows to bug the room
(about 5 meters) around the device with an SMS-command that tells
the device to make an incoming call. AutoFon SE-Mayak can option
-
ally be connected to a car alarm system. If the sensor activates, even
if the device is in sleeping mode, admin receives an SMS-report to
which coordinates can be included. It is also possible to send an SMS
to activate the external control system, such as the engine’s start, stop
system, front lights, etc.
OPERATION PRINCIPLE
