Introduction
1. INSTRUCTIONS FOR SAFE AND PROPER USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND
THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE
PLACE FOR THE WHOLE WORKING LIFE OF THE COOKING HOB. WE
ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS
THEREIN BEFORE USING THE COOKING HOB. ALSO KEEP THE SERIES
OF NOZZLES SUPPLIED. INSTALLATION MUST BE CARRIED OUT BY
QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN
FORCE. THIS APPLIANCE IS INTENDED FOR DOMESTIC USES AND
CONFORMS TO CURRENT REGULATIONS IN FORCE. THE APPLIANCE
HAS BEEN BUILT TO CARRY OUT THE FOLLOWING FUNCTIONS:
COOKING AND HEATING-UP OF FOOD. ALL OTHER USES ARE
CONSIDERED IMPROPER.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
IMPROPER USE.
DO NOT LEAVE THE PACKING IN THE HOME ENVIRONMENT.
SEPARATE THE VARIOUS WASTE MATERIALS AND TAKE THEM TO
THE NEAREST SPECIAL GARBAGE COLLECTION CENTRE.
IT IS OBLIGATORY FOR THE ELECTRICAL SYSTEM TO BE GROUNDED
ACCORDING TO THE METHODS REQUIRED BY SAFETY RULES.
THE PLUG TO BE CONNECTED TO THE POWER CABLE AND THE
SOCKET MUST BE THE SAME TYPE AND MUST CONFORM TO
CURRENT REGULATIONS.
NEVER UNPLUG BY PULLING ON THE CABLE.
IMMEDIATELY AFTER INSTALLATION CARRY OUT A BRIEF INSPECTION
TEST OF THE COOKING HOB, FOLLOWING THE INSTRUCTIONS
BELOW. SHOULD THE APPLIANCE NOT FUNCTION, DISCONNECT IT
FROM THE SUPPLY AND CALL THE NEAREST TECHNICAL ASSISTANCE
CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE POSITION
"ZERO" (OFF) WHEN YOU FINISH USING THE HOB.
22
Содержание
- Adaptation to different types of gas _______________ 29 1
- Cleaning and maintenance ___________________________ 36 1
- Contents 1
- Electrical connection ______________________________ 26 1
- Final operations_____________________________________ 32 1
- Gas connection______________________________________ 27 1
- Instructions for safe and proper use_______________ 22 1
- Positioning of hob ___________________________________ 24 1
- Using the hob ________________________________________ 34 1
- Instructions for safe and proper use 2
- Introduction 2
- Introduction 3
- The manufacturer declines all responsibility for damage to persons or things caused by non observance of the above prescriptions or by interference with any part of the appliance or by the use of non original spares 3
- Attachment to support structure 4
- Instructions for the installer 4
- Positioning of hob 4
- Instructions for the installer 5
- Electrical connection 6
- Instructions for the installer 6
- Gas connection 7
- Instructions for the installer 7
- Connection to lpg 8
- Discharge of combustion products 8
- Instructions for the installer 8
- Ventilation of rooms 8
- Adaptation to different types of gas 9
- Instructions for the installer 9
- Removing the hob 9
- Instructions for the installer 10
- Loosen screw a and push support b all the way use a double head wrench to remove nozzle c and assemble the suitable one following the instructions indicated in the reference charts with respect to the type of gas to use the screwing torque of the nozzle should never exceed 3 nm reposition support b so that nozzle c is covered perfectly move the venturi tube d to regulate the air flow until distance x is reached indicated in the chart in paragraph 5 regulation of primary air and then secure the tube by means of screw a after the regulations have been carried out restore the seals with sealing wax or equivalent material 10
- Regulation for lpg 10
- Instructions for the installer 11
- Referred to distance x in mm 11
- Regulation for natural gas 11
- Regulation of primary air 11
- The hob has been inspected for g20 2h natural gas at a pressure of 20 mbar to allow the unit to work with this type of gas perform the same operations described in paragraph 5 regulation for lpg but choose the nozzles and regulate the primary air for natural gas as shown in the following table and in paragraph 5 regulation of primary air after the regulations have been carried out restore the seals with sealing wax or equivalent material 11
- Final operations 12
- Instructions for the installer 12
- Regulation of minimum for lpg 12
- Regulation of minimum for natural gas 12
- Arrangement of burners on hob 13
- Instructions for the installer 13
- Lubrication of gas taps 13
- Ignition of the burners with safety device 14
- Insructions for the user 14
- Practical advice for using the burners 14
- Using the hob 14
- A few precautions are necessary if you wish to use a griddle plate leave a gap of at least 160 mm between the edge of the griddle plate and the side wall 15
- Diameter of containers 15
- Do not allow the burner flames to extend beyond the edge of the griddle plate 15
- If one of the burners close to the wooden rear wall is of triple flame type leave a gap of at least 160 mm between this wall and the edge of the griddle plate 15
- Insructions for the user 15
- Operate the burners underneath the griddle plate for 10 minutes at maximum power then turn them down to the minimum setting never use the griddle plate for more than 45 minutes 15
- Using a griddle plate 15
- Cleaning 16
- Cleaning and maintenance 16
- Cleaning of cooking hob components 16
- Food stains or residues 16
- Ignition plugs and safety devices 16
- Insructions for the user 16
- Regular daily cleaning of the hob 16
