2. Functional Description

Intended Use

The measuring tool is intended for horizontal and diagonal alignment of tiles and laminate ooring panels.

The measuring tool is suitable for operation exclusively in enclosed work sites.

3. Specications

1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation).

Working range 7 m

(1)

Angular accuracy ±0.5 mm/m

Operating temperature +5 °C ... +40 °C

Storage temperature – 20 °C ... +70 °C

Relative air humidity max. 90 %

Laser class 2

Laser type 635 nm < 2 mW

Batteries 3 x 1.5 V LR6 (AA)

Operating life time approx. 15 h

Weight 360 g

Dimensions 240 x 128 x 59 mm
